ball mill
Description: Ball mill is the key equipment in the production of aluminum paste. Add aluminum powder, additives and other raw materials into the ball mill, and use steel balls as grinding media to crush the materials for ball milling.
| Technical parameters of ball mill | |
| Model | φ1250x2500 |
| Size | 4900*1900*1800mm |
| Approximate weight： | 4600kg |
| Motor | 6-37kw |
| Materia | cylinder body Q355D steel, lifting rib 45# steel |
| Speed | 36r/min |
| Reducer | ZDY200 |
Our Internal cooling ball mill has the following advantages:
-The first internal cooling method: constant temperature cooling, reuse of cooling water, energy saving, environmental protection and noise reduction
-The body of the ball mill is integrated with the chassis: flexible movement and simple installation
-Adopt reducer-gear rotation mode: transmission efficiency and stable operation
-Adopt frequency conversion starting method: improve the service life of the electromechanical, and freely control the speed according to different process requirements
